Heavy Duty Steel Grating
Product Description
Heavy Duty Steel Grating (also known as Heavy Load Steel Grating) is manufactured from hot-dipped galvanized steel or stainless steel material through a series of processes including slotting (perforating), press-locking, welding, and precision finishing.
Press-Locked Heavy Duty Grating incorporates all the advantages of welded steel grating—such as high strength, excellent corrosion resistance, and virtually maintenance-free performance—while offering additional benefits: uniform mesh configuration, lightweight yet robust structure, smooth appearance, and an aesthetically pleasing style.
Heavy Duty Steel Grating is widely used in both commercial and civil construction, theaters, subway and metro systems, and municipal engineering projects. It is specifically designed for applications requiring exceptional load-bearing capacity, such as airports, expressways, industrial platforms, and port terminals.
Item: Heavy Duty Steel Grating
Material: Hot-dipped Galvanized Steel Or Stainless Steel
Type: Welded Type (W) or Press-Locked / Swage-Locked Type
Structure: Bearing Bar (Flat Bar) / Cross Bar / Twisted Square Bar
Surface: Serrated Surface (Serrated Type) / Plain Surface
Bearing Bar Size: 50×5、50×6、60×5、65×5 etc.
Bearing Bar Pitch: 30mm, 40mm, 60mm etc.
Cross Bar Size: 8mm, 10mm etc.
Cross Bar Pitch: 50mm, 100mm etc.
Grating Size: Customizable
